Rail Way Weighbridge

Get a Price/Quote

MOQ : 1 Piece

Rail Way Weighbridge Specification

Color
Blue/Grey

Structure
Modular Platform

Power Supply
220V/50Hz

Accuracy
0.05%

Loading Capacity
Up to 120 Tons

Display Type
Digital

Voltage
220 V AC

Material
Mild Steel

Rail Way Weighbridge Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Week

Delivery Time
3-4 Days

About Rail Way Weighbridge

We are the trusted name when it comes to manufacturing and supply Rail Way Weighbridge. Offered range is for weighing loaded rail wagons. Our weighbridge is working successfully in various railways industries due to its high performance and accurate measurements. Entire stock is manufactured by premium quality of raw materials sourced from genuine vendors of industry. Our research team develop the Rail Way Weighbridge following high class international norms.

Further Details:

Can bear heavy axle load
Can sustain high temperature
Requires low maintenance

Further details:

Standard Static Configuration

Rail type : 115 lb AREA (consult factory for other sizes)
Rail length : 70 (1.78 m)
Active weighing length per section : 8 (20 cm)
Mounting : Direct to existing ties and ballast
Type of weighing : Two draft or full draft
Number of Weighline sections : Two draft - four, Full draft - eight
Maximum axle load : 80,000 lb (40,000 kg)
Maximum car weight : 320,000 lb (160,000 kg)
Scale division size : 100 lb (50 kg), switchable to 20 lb (10 kg) for calibration

Static accuracy:

Full draft : +0.25% or +200 lb (100 kg), whichever is greater
Two draft : +0.4% or +300 lb (150 kg), whichever is greater
Operating temperature range : -20^o F to 120^o F (-28^o C to 49^o C)
Temperature compensation : Span and zero
Weight : 230 lb (105 kg) per rail assembly

Modular Platform Design

Our weighbridge features a modular platform constructed from high-grade mild steel, providing exceptional durability and easy installation or expansion. This structure is ideal for diverse site conditions and ensures long-term stability, making it suitable for continuous heavy-duty operations in railway environments.

Precision and Performance

With an accuracy of 0.05% and a capacity of up to 120 tons, this weighbridge delivers dependable, precise measurement for every rail wagon. The digital display streamlines the weighing process, reducing errors and supporting efficient logistics operations.

Versatile Supply and Services

Serving as a producer, importer, wholesaler, fabricator, retailer, and supplier across India, we cater to diverse client needs. Our expertise ensures seamless installation, maintenance, and after-sales support for all customers.

FAQs of Rail Way Weighbridge:

Q: How is the Rail Way Weighbridge installed and operated?

A: The weighbridge features a modular platform that is assembled on-site using mild steel components. It operates with a standard 220V AC power supply and includes a digital display for easy monitoring. Professional installation ensures optimal positioning and calibration for accurate measurement.

Q: What are the main benefits of using this weighbridge for railway applications?

A: The main benefits include high accuracy (0.05%), a large 120-ton capacity, a modular structure for customizable length, and a robust digital display for efficient operation. These features streamline railcar weighing, improve logistics, and enhance operational safety.

Q: When should calibration and maintenance be performed for best accuracy?

A: Calibration should be conducted at installation, after major repairs, or periodically (typically annually or as recommended) to maintain accuracy. Routine maintenance checks ensure long-term reliability and performance in demanding railway settings.

Q: Where can this weighbridge be deployed within India?

A: This modular weighbridge is suitable for deployment at rail yards, industrial complexes, and logistics hubs across India. Its design accommodates varying site conditions and scales seamlessly to meet the needs of different rail infrastructure projects.

Q: What is the process for purchasing and installing a Rail Way Weighbridge?

A: Contact our sales team or authorized dealer for consultation based on your site requirements. After order confirmation, our team manages delivery, installation, platform assembly, calibration, and user training, ensuring a seamless and efficient setup.

Q: How is the digital display used during weighing operations?

A: The digital display provides real-time weight readings, facilitating easy tracking, error checks, and efficient documentation. It supports the operator in quickly verifying each railcars weight without manual calculations.

Q: What are the available colors and structural advantages?

A: The weighbridge is offered in blue or grey color options. Its modular mild steel structure allows for flexibility in length, robust load handling, and easy maintenance, making it a long-lasting solution for railway weighing requirements.
